Input Channels                   Mono (MIC/LINE): 1 including HEADSET MIC (Plug-in Power);

                                             Stereo (LINE): 1;

                                             Mono (GUITAR): 1;

                                             USB PLAYBACK: 1;

Output Channels                MAIN L/R OUT: 1;

                                             PHONES: 2 including HEADSET PHONES;

Bus                                       Stereo: 1

Input Channel Function

              CH1 MIC/LINE      GAIN, -14~+40 dB;

                                            +48V, Phantom Power,LED;

                                            PEAK LED LED turns on when the signal reaches 3 dB below clipping level.

                                            2 BAND EQ, 80Hz,12KHz, ±15dB;

                                            EFFECT, Digital ECHO;



              CH2 INST/LINE      IMPEDANCE Switch;

                                            SIGNAL LED, -3dB;

                                             LEVEL Knob;

              CH3-CH4 LINE      SIGNAL LED, -3dB;

                                            LEVEL Knob;

              USB Audio           Stereo Input / Stereo Output;

                                             USB Audio Class 2.0 compliant;

                                             Sampling Frequency: Max 48 kHz, Bit Depth: 16-bit;

                                             Type B connector;

                                             Playback LEVEL Knob;

Level Meter                        2x2 point LED meter (CLIP, SIG);

Power Requirements         DC 5 V, 500 mA

Power Consumption         Max. 2.5 W

Dimensions (WxHxD)        113 mm x 40 mm x 135 mm (4.4" x 1.6" x 5.3" )

Net Weight                           0.6 kg (1.3 lbs)
