Input Channels      Mono (MIC/LINE)/INST: 1 ;



                         Stereo (LINE): 1;



                         USB PLAYBACK: 1;



Output Channels    MAIN L/R OUT: 1;



                          PHONES: 1 ;



Bus                     Stereo: 1



Input Channel Function



    CH1 MIC/INST(LINE)   GAIN, -14~+40 dB;



                           +48V, Phantom Power,LED;



                           PEAK LED LED turns on when the signal reaches 3 dB below clipping level.



                           IMPEDANCE Switch;



    CH2-CH3 LINE         SIGNAL LED, -3dB;



                           LEVEL Knob;



    USB Audio             Stereo Input / Stereo Output;



                           USB Audio Class 2.0 compliant;



                           Sampling Frequency: Max 48 kHz, Bit Depth: 16-bit;



                           Type B connector;



                           Playback LEVEL Knob;



Level Meter            2 point LED meter (CLIP, SIG);



Power Requirements   DC 5 V, 500 mA



Power Consumption    Max. 2.5 W



Dimensions (WxHxD)   98 mm x 40 mm x 120 mm (3.9" x1.6" x 4.7" )



Net Weight                  0.4 kg (0.9 lbs)
