FEATURES
UHF 600-928MHz frequency range
True diversity for maximun range and dropout protection
PLL Synthesized circuit, pre-set 100 selectable frequencies
IR sync downloading the frequency from receiver
LCD display shows status of frequency, AF and RF signal etc
15 systems can work simultaneously without interfernce
EIA standard 1/2U rack-mountable metal chassis
Up to 500 feet(150m) line-of-sight operating range
Designed for lavalier,heaset and all wired instruemnt mics applications

SPECIFICATION
Comprehensive Performance:
Frequency Range: 600-928MHz
Modulation Mode: FM
Dynamic Range: >100dB
Frequency Response: 60Hz-17KHz±3dB
Total Harmonic Distortion: <0.5% at 1KHz
Signal/Noise Ratio: ?105dB

Receiver:
Frequency Range: 600-928MHz
Receive Sensitivity: -110dBm (sinad ?30dB)
Signal/Noise Ratio: >105dB
Power Supply: DC12V-18V / 500mA
Dimensions:210*170*44mm
Audio Output: 1*XLR socket, 1*6.3mm jack socket

Transmitter:
Frequency Range:740-765MHz
RF Power: 10mW
Microphone Type: Dynamic
Directivity: Cardioid
Battery Voltage: 3V (2x1.5V AA Battery)
Power Consumption: 8 hours, battery-dependent
Uyumlu Marka ve Modeller
Acemic>>EX-100/MINI-BP
